CAE Fidesys 9.0 Documentation

Command Line Usage Instructions

Step 3: Create a Cylinder

Now you need to create a cylinder, which will be used to cut a hole in the brick. This action is performed by the command:

FIDESYS> create cylinder height 12 radius 3

As a result, you will see in the Fidesys graphics window both a brick and a cylinder, as shown below:

Fig. 5 Brick and cylinder
